· AMD EPYC™ 7001 series (Naples) Processors, AMD EPYC™ 7000 Series
· System on Chip
· 1 TB ECC Registered, DDR4-2666MHz SDRAM in 8 DIMMs
8-channel memory bus
· 3 PCI-E 3.0 x16
3 PCI-E 3.0 x8
M.2 Interface: 1 PCI-E 3.0 x4
M.2 Form Factor: 2280, 22110
M.2 Key: M-Key
· Broadcom 3008 SAS3 (12 Gbps) controller for 8 SAS3 (12 Gbps) ports; RAID 0,1,10 SATA3 (6 Gbps)8 SATA3 (6 Gbps) ports;
· 2 1GbE with Intel® I210, 1 Realtek RTL8211F PHY (dedicated IPMI)

• 10th Generation Intel® Core™ i9/Core™ i7/Core™ i5/Core™ i3/Pentium®/Celeron® Processor, Intel® Xeon® W-1200 Processors
Single Socket LGA-1200 (Socket H5) supported, CPU TDP supports Up to 125W TDP

• Intel® W480E

• Up to 128GB Unbuffered ECC/non-ECC UDIMM, DDR4-2933MHz, in 4 DIMM slots

• 1 PCI-E 3.0 x16,
1 PCI-E 3.0 x4 (in x8 slot),
1 PCI-E 3.0 x4
1 M.2 M-Key SATA/PCI-E 3.0 x4, 2280/22110
1 M.2 E-Key CNVi/PCI-E 3.0 x1, 2230

• 1 VGA D-Sub Connector port, 2 DP++(Dual-Mode DisplayPort) ports, 1 DVI - D port

• Intel® W480E controller for 4 SATA3 (6 Gbps) ports; RAID 0,1,5,10

• Dual LAN with Intel® X550 10GBase-T Ethernet Controller
Single LAN with Intel® PHY I219LM LAN controller
Single LAN with Intel® Ethernet Controller I210-AT

· AMD EPYC™ 7000 Series, AMD EPYC™ 7001 series (Naples) Processors
· System on Chip
· 2 TB ECC Registered, DDR4-2666MHz SDRAM in 16 DIMMs
8-channel memory bus
· 2 PCI-E 3.0 x16
3 PCI-E 3.0 x8
M.2 Interface: 1 SATA/PCI-E 3.0 x2
M.2 Form Factor: 2280, 22110
M.2 Key: M-Key
· SATA3 (6 Gbps)10 SATA3 (6 Gbps) ports; AMD SoC
· 2 Intel® X550 10GBase-T Ethernet Controller,
1 Realtek RTL8211F PHY (dedicated IPMI)

• 2nd Gen Intel® Xeon® Scalable Processors and Intel® Xeon® Scalable Processors,

• Dual Socket LGA-3647 (Socket P) supported, CPU TDP support Up to 205W TDP, 2 UPI up to 10.4 GT/s

• Intel® C621

• Up to 4TB 3DS ECC RDIMM, DDR4-2933MHz; Up to 4TB 3DS ECC LRDIMM, DDR4-2933MHz, in 16 DIMM slots

• 3 PCI-E 3.0 x16 (in x16 slot),
3 PCI-E 3.0 x8

• 1 VGA D-Sub Connector port

• Intel® C621 controller for 8 SATA3 (6 Gbps) ports; RAID 0,1,5,10

• Dual LAN with GbE from C621

· AMD EPYC™ 7002 series (Rome) Processors, AMD EPYC™ 7002 series and next generation processors
· System on Chip
· 8 TB ECC Registered, DDR4-3200MHz
· 20 PCI-E 4.0 x8 SlimSAS to PCI-E board
1 PCI-E 4.0 x16 for AIOM networking
· Marvell 88SE9230 controller SATA3 (6 Gbps) controller for 4 SATA3 (6 Gbps) ports; RAID 0,1,10

• Intel® Xeon® W-2100 Processors, Intel® Xeon® W-2200 Processors
Single Socket LGA-2066 (Socket R4) supported, CPU TDP support Up to 165W TDP

• Intel® C422

• Up to 512GB Registered ECC RDIMM, DDR4-2666MHz; Up to 1TB Registered ECC LRDIMM, DDR4-2666MHz, in 8 DIMM slots(DDR4-2933MHz: RDIMM Max. Memory Capacity 256GB Registered ECC, LRDIMM Max. Memory Capacity 512GB Registered ECC)

• 3 PCI-E 3.0 x16,
1 PCI-E 3.0 x4
***3xPCI-E3.0 x16 Slots(8/16/16 (Skylake-W 48 lanes), 1xPCI-E3.0x4 slots***
M.2 Interface: 2 PCI-E 3.0 x4
M.2 Form Factor: 22110
M.2 Key: M-Key (RAID 0,1 support)
*M-Key for SSD and Optane(up to Intel POR). Intel VROC license kit is needed to enable RAID.
U.2 Interface: 2 PCI-E 3.0 x4

• Intel® C422 controller for 6 SATA3 (6 Gbps) ports; RAID 0,1,5,10
*iRST enabled, only SATA2 to SATA5 support RAID.

• Single LAN with Intel® PHY I219LM LAN controller
Single LAN with Aquantia 5G LAN chip AQC108

· AMD EPYC™ 7002 series (Rome) Processors, AMD EPYC™ 7002 series and next generation processors
· System on Chip
· 8 TB ECC Registered, DDR4-3200MHz SDRAM in 32 DIMMs
· 19 PCI-E 4.0 x8 SlimSAS
· 1 PCI-E 4.0 x4 SlimSAS

• 2nd Gen Intel® Xeon® Scalable Processors and Intel® Xeon® Scalable Processors
Single Socket LGA-3647 (Socket P) supported, CPU TDP support Up to 205W TDP

• Intel® C621

• Up to 3TB 3DS ECC RDIMM, DDR4-2933MHz; Up to 3TB 3DS ECC LRDIMM, DDR4-2933MHz
Or 3TB DCPMM, DDR4-2666MHz, in 12 DIMM slots

• 4 PCI-E 3.0 x16,
3 PCI-E 3.0 x8 (in x16 slot),
PCI-Ex16 Slot#1 shares with M.2, Slot#2 shares with Slot#3(NA/16,8/8), Slot#4 shares with Slot#5(NA/16,8/8), Slot#6 shares with Slot#7(NA/16,8/8)
M.2 Interface: 4 PCI-E 3.0 x4, RAID 0 & 1
M.2 Form Factor: 2242/2260/2280/22110
M.2 Key: M-Key
M.2 support RAID 0,1(up to RAID 5, 10), VROC key is required for Raid.

• 1 VGA port,
VGA connector is dedicated for IPMI.

• Intel® C621 controller for 8 SATA3 (6 Gbps) ports; RAID 0,1,5,10

• Single LAN with Intel® Ethernet Controller I210-AT
Single LAN with Aquantia® AQC107 10G Ethernet Controller
Single LAN with Realtek RTL8211E PHY (dedicated IPMI)

· AMD EPYC™ 7002 series (Rome) Processors, AMD EPYC™ 7002 series and next generation processors
· System on Chip
· 8 TB ECC Registered, DDR4-3200MHz SDRAM in 32 DIMMs
· 4 PCI-E 4.0 x8 SlimSAS
1 PCI-E 4.0 x4 SlimSAS
M.2 Interface: 2 PCI-E 4.0 x4
M.2 Form Factor: 22110
M.2 Key: M-Key

• 2nd Gen Intel® Xeon® Scalable Processors and Intel® Xeon® Scalable Processors, Intel® Xeon® W-32xx Processor
Single Socket LGA-3647 (Socket P) supported, CPU TDP support 205W TDP

• Intel® C621

• Up to 3TB 3DS ECC RDIMM, DDR4-2933MHz; Up to 2TB 3DS ECC LRDIMM, DDR4-2933MHz
Or 3TB DCPMM, DDR4-2666MHz, in 12 DIMM slots
Xeon-W 32xx supports up to 2TB 3DS ECC RDIMM/LRDIMM, Xeon-W 32xx supports up to 1TB 3DS RDIMM/LRDIMM.

• 4 PCI-E 3.0 x16,
3 PCI-E 3.0 x8 (in x16 slot),
PCI-Ex16 Slot 1 shares with M.2, Slot 2 shares with Slot 3(NA/16,8/8), Slot 4 shares with Slot 5(NA/16,8/8), Slot 6 shares with Slot 7(NA/16,8/8)
(16/NA/16/NA/16/NA/16 or 16/8/8/8/8/8/8)
M.2 Interface: 4 PCI-E 3.0 x4, RAID 0 & 1
M.2 Form Factor: 2242/2260/2280/22110
M.2 Key: M-Key
M.2 support RAID 0,1(up to RAID 5, 10), VROC key is required for Raid.

• 1 VGA port,
VGA connector is dedicated for IPMI.

• Intel® C621 controller for 8 SATA3 (6 Gbps) ports; RAID 0,1,5,10

• Single LAN with Intel® Ethernet Controller I210-AT
Single LAN with Aquantia® AQC107 10G Ethernet Controller
Single LAN with Realtek RTL8211E PHY (dedicated IPMI)

· AMD EPYC™ 7001 series (Naples) Processors, AMD EPYC™ 7000 Series
· System on Chip
· 2 TB ECC Registered, DDR4-2666MHz SDRAM in 16 DIMMs
8-channel memory bus

· 1 PCI-E 3.0 x32 Left Riser Slot
1 PCI-E 3.0 x16 Right Riser Slot
M.2 Interface: 2 PCI-E 3.0 x2
M.2 Form Factor: 2280, 22110
M.2 Key: M-Key
M.2-C1 can support PCI-E x4, when only install 1pcs M.2

· SATA3 (6 Gbps)16 SATA3 (6 Gbps) ports; Hybrid use from Four (4) internal NVMe ports by BIOS option.
SATA3 (6 Gbps)2 SATA3 (6 Gbps) ports; Asmedia ASM1061

· 2 Broadcom BCM57416 10GBase-T,
1 Realtek RTL8211F PHY (dedicated IPMI)

• 8th/9th Generation Intel® Core™ i9/Core™ i7/Core™i5/Core™i3/Pentium®/Celeron® Processor.
Single Socket LGA-1151 (Socket H4) supported, CPU TDP support Up to 95W TDP

• Intel® Q370

• Up to 128GB Unbuffered non-ECC UDIMM, DDR4-2666MHz, in 4 DIMM slots

• 1 PCI-E 3.0 x16,
2 PCI-E 3.0 x4 (in x8 slot)
M.2 Interface: 1 SATA/PCI-E 3.0 x4
M.2 Form Factor: 2280/22110
M.2 Key: M-Key

• 1 DVI - I port, 2 DP (DisplayPort) ports,
3 Independent Displays

• Intel® Q370 controller for 5 SATA3 (6 Gbps) ports; RAID 0,1,5,10

• Single LAN with Intel® Ethernet Controller I210-AT
Single LAN with Intel® PHY I219LM LAN controller
