• Dual-Path Storage Enclosure for High Availability Applications

• Support two canister controllers; 1+1 redundant for Dual-Path Enclosure

• Support 90 3.5"/2.5" Top Loading SAS3 12Gb/s Hot-Swappable HDDs

• 6x SAS3.0 IO ports (MiniSAS HD/SFF-8644) per node

• Dedicated IPMI RJ45 management port

• Redfish OOB management protocol support

• SCSI Enclosure Services SES-4 support

• Hot-swappable Tool-less Modular Design for Easy Service and Easy Maintenance

• Redundant Titanium 2000W power supply

• Extreme High Density and High Capacity Storage Chassis support 60 x 3.5" Top Loading SAS/SATA 12Gb/s Hot Swapping HDD/SSD Bays

• Tool-less HDD tray with HDD LED indicator

• Dual Expander Backplane Boards support SAS3/2 HDDs with 12Gb/s throughput

• 8x Mini-SAS HD ports for Internal / External Cascading Expander Combination for high performance, high availability or high redundancy requirements

• 1x IPMI port for Remote System Power on/off and system monitoring

• Support NTP for time synchronization & RTC battery backup

• 1600W (1+1) Redundant High-efficiency Platinum Level Power Supplies

• Optimized cooling w/ 5x 80x38mm rear hot-swap fans

• Support front LCD panel for system status & error info (Option)

• Ideal for Cloud backup, data Replication or High density Archive Storage Applications 10. Qualified SAS HBA / controller:
AOC-SAS3-9300-8E - 12Gb/s 2-external ports SAS3 HBA
AOC-SAS3-9380-8E - 12Gb/s 2-external ports SAS3 RAID Controller

• Extreme High Density and High Capacity Storage Chassis support 60 x 3.5" Top Loading SAS/SATA 12Gb/s Hot Swapping HHD/SSD Bays

• Tool-less HDD tray with HDD LED indicator

• Single Expander Backplane Boards support SAS3/2 HDDs with 12Gb/s throughput

• 4x Mini-SAS HD ports for Internal / External Cascading Expander Combination for high performance, high availability or high redundancy requirements

• 1x IPMI port for Remote System Power on/off and system monitoring

• Support NTP for time synchronization & RTC battery backup

• 1600W (1+1) Redundant High-efficiency Platinum Level Power Supplies

• Optimized cooling w/ 5x 80x38mm rear hot-swap fans

• Support front LCD panel for system status & error info (Option)

• Ideal for Cloud backup, data Replication or High density Archive Storage Applications 10. Qualified SAS HBA / controller :
AOC-SAS3-9300-8E - 12Gb/s 2-external ports SAS3 HBA
AOC-SAS3-9380-8E - 12Gb/s 2-external ports SAS3 RAID Controller

• Extreme High Density and High Capacity Storage Chassis support 45 x 3.5" Top Loading SAS/SATA 12Gb/s Hot Swapping HDD/SSD Bays

• Tool-less HDD tray with HDD LED indicator

• Single Expander Backplane Boards support SAS3/2 HDDs with 12Gb/s throughput

• 4x Mini-SAS HD ports for Internal / External Cascading Expander Combination for high performance, high availability or high redundancy requirements

• 1x IPMI port for Remote System Power on/off and system monitoring

• Support NTP for time synchronization & RTC battery backup

• 1600W (1+1) Redundant High-efficiency Platinum Level Power Supplies

• Optimized cooling w/ 5x 80x38mm rear hot-swap fans

• Support front LCD panel for system status & error info (Option)

• Ideal for Cloud backup, data Replication or High density Archive Storage Applications 10. Qualified SAS HBA / controller:
AOC-SAS3-9300-8E - 12Gb/s 2-external ports SAS3 HBA
AOC-SAS3-9380-8E - 12Gb/s 2-external ports SAS3 RAID Controller

• Extreme High Density and High Capacity Dual-path Storage Enclosure

• Support 90 x 3.5" or 2.5" Top Loading SAS3 12Gb/s Hot-swappable HDDs

• Hot-swappable Expanders with redundant BMC for Remote System Power on/off and monitoring

• Hot-swappable Tool-less Modular Design for Easy Service and Easy Maintenance

• High Performance up to 20+ GB/s data transfer rate

• Tool-less HDD tray with HDD LED indicator

• SCSI Enclosure Services (SES 3.0) compliant

• Flexible to configure up to 4 Hosts HDD Zoning and individual HDD power cycling

• Slide Rails and Cable Management Arm included 10. Qualified SAS HBA / controller:
AOC-SAS3-9300-8E - 12Gb/s 2-external ports SAS3 HBA
AOC-SAS3-9380-8E - 12Gb/s 2-external ports SAS3 RAID Controller

• 44x (24 front + 20 rear) 3.5" hot-swap SAS drive bays supporting SAS3/2 HDDs with 12Gbps throughput

• Redundant 1200W Titaninum Level (1+1) power supplies with PMBus

• 7x8cm (middle) hot-swap redundant cooling fans

• SAS3 (12Gbps) backplane with dual expanders supports SAS3 drives for load balancing and redundancy

• JBOD Power Control Board with IPMI for remote monitor and power on-off

• 8x External mini SAS HD (SFF 8644) connectivity and IPMI RJ45 port

• Palletized packaging for easy shipping and handling

• Qualified SAS HBA / controller:
AOC-SAS3-9300-8E - 12Gb/s 2-external ports SAS3 HBA
AOC-SAS3-9380-8E - 12Gb/s 2-external ports SAS3 RAID Controller

• 44x (24 front + 20 rear) 3.5" hot-swap SAS/SATA drive bays supporting SAS3/2 or SATA3 HDDs with 12Gbps throughput

• Redundant 1200W Titaninum Level (1+1) power supplies with PMBus

• 7x 8cm (middle) hot-swap redundant cooling fans

• SAS3 (12Gbps) backplane with single expander supports SAS3/SATA3 drives for capacity expansion

• JBOD Power Control Board with IPMI for remote monitor and power on-off

• 4x External mini SAS HD (SFF 8644) connectivity and IPMI RJ45 port

• Palletized packaging for easy shipping and handling

• Qualified SAS HBA / controller:
AOC-SAS3-9300-8E - 12Gb/s 2-external ports SAS3 HBA
AOC-SAS3-9380-8E - 12Gb/s 2-external ports SAS3 RAID Controller

• 4U Double-Density SAS3 JBOD storage chassis

• 90 x 3.5" hot-swap SAS/SATA drive bay with SES3

• 90x 3.5" HDDs in 45x Hot-swap drive bays (2x HDD per bay) SAS or enterprise SATA HDD only recommended

• 48-port SC847D SAS3 12Gbps front expander board (cascade type configuration)

• 48-port 4U SC847D SAS2/SAS3 system/JBOD front midplane, support up to 48x 3.5-inch SAS2/SAS3/SATA3 HDD

• 42-port 4U SC847D SAS2/SAS3 JBOD rear midplane, support up to 42x 3.5-inch SAS2/SAS3/SATA3 HDD

• 1U 2000W Titanium Redundant Power Supply W/PMbus

• 7 x 92mm hot-swap fan(s)

• 4U High Density Storage JBOD Chassis with capacity 90 x 3.5" hot-swappable HDDs in 45 drive bays

• Single Expander Board and Front/Rear Backplane Boards support SAS3/2 or SATA3 HDDs with 12Gb/s throughput

• 4 x Mini-SAS HD ports for Internal / External Cascading Expander Combination for high performance, high availability or high redundancy requirements

• 1x IPMI port for Remote System Power on/off

• Support NTP for time synchronization

• 2000W (1+1) 96% efficient Titanium level power supplies

• 7 x 92mm high efficient hot-swappable fans for best system cooling

• Ideal for Cloud backup, data Replication or High desnsity Archive Storage Applications

• 4U chassis support for SMCI Proprietary WIO motherboards; max.
motherboard size - 12" x 13", 13" x 13.68" * Support up to 12"x13" MB with rear 2.5" HDD option installed

• 36 x 3.5" hot-swap drive bay, optional 2 x 2.5" hot-swap drive bay

• 1U 1200W/1000W Titanium Power Supply W/PMbus W76xL336xH40mm

• WIO Slots (4x Full-height, Full-length + 3x Low-profile)

• 7 x 8cm (7000 RPM) hot-swap PWM cooling fan(s)

• 4U Chassis for motherboard support size: (12" x 10") (13.68" x 13") (9.6" x 9.6")

• 36 x 3.5" hot-swap SAS/SATA drive bay with SES3, optional 2 x 2.5" hot-swap drive bay

• 12-port 2U SAS3 12Gbps dual-expander backplane, support up to 12x 3.5-inch SAS3/SATA3 HDD/SSD

• 24-port 4U SAS3 12Gbps dual-expander backplane, support up to 24x 3.5-inch SAS3/SATA3 HDD/SSD (secondary expander port only connects to dual-port SAS devices, single-port SATA will not have this redundancy feature)

• 1U 1200W/1000W Titanium Power Supply W/PMbus W76xL336xH40mm

• 7 low-profile expansion slot(s)

• 7 x 80mm high-performance fan(s)

• 4U Chassis for motherboard support size: (12" x 10") (13.68" x 13") (9.6" x 9.6")

• 36 x 3.5" hot-swap SAS/SATA drive bay with SES3, optional 2 x 2.5" hot-swap drive bay

• 12-port 2U SAS3 12Gbps single-expander backplane, support up to 8x 3.5-inch SAS3/SATA3 HDD/SSD and 4x NVMe/SAS3/SATA3 storage devices

• 24-port 4U SAS3 12Gbps single-expander backplane, support up to 24x 3.5-inch SAS3/SATA3 HDD/SSD

• 1U 1200W/1000W Titanium Power Supply W/PMbus W76xL360xH40mm

• 7 low-profile expansion slot(s)

• 7 x 80mm high-performance fan(s)
