· AMD EPYC™ 7002 series (Rome) Processors, AMD EPYC™ 7002 series and next generation processors
· System on Chip
· 2 TB ECC Registered, DDR4-3200MHz SDRAM in 8 DIMMs
· 1 PCI-E 4.0 x32 Left Riser Slot
1 PCI-E 4.0 x16 Right Riser Slot
M.2 Interface: 2 SATA/PCI-E 3.0 x2
M.2 Form Factor: 2280, 22110
M.2 Key: M-Key
M.2-C1 can support PCI-E x4, when only install 1pcs M.2

· SATA3 (6 Gbps)16 SATA3 (6 Gbps) ports; Hybrid use from Four(4) internal NVMe ports by BIOS option.
SATA3 (6 Gbps)2 SATA3 (6 Gbps) ports; Asmedia ASM1061
2 Broadcom BCM57416 10GBase-T,
1 Realtek RTL8211F PHY (dedicated IPMI)

• 8th/9th Generation Intel® Core™ i9/Core™ i7/Core™i5/Core™i3/Pentium®/Celeron® Processor, Intel® Xeon® E-2100 Processor, Intel® Xeon® E-2200 Processor.
Single Socket LGA-1151 (Socket H4) supported, CPU TDP support Up to 95W TDP

• Intel® C246

• Up to 128GB Unbuffered ECC/non-ECC UDIMM, DDR4-2666MHz, in 4 DIMM slots

• 1 PCI-E 3.0 x16,
2 PCI-E 3.0 x4 (in x8 slot)
1 M.2 M-Key SATA/PCI-E 3.0 x4, 2280/22110

• 1 VGA D-Sub Connector port, 1 DVI - I port, 2 DP (DisplayPort) ports,
3 Independent Displays

• Intel® C246 controller for 5 SATA3 (6 Gbps) ports; RAID 0,1,5,10

• Single LAN with Intel® Ethernet Controller I210-AT
Single LAN with Intel® PHY I219LM LAN controller

· AMD EPYC™ 7002 series (Rome) Processors, AMD EPYC™ 7002 series and next generation processors
· System on Chip
· 4 TB ECC Registered, DDR4-3200MHz SDRAM in 16 DIMMs
8-channel memory bus

· 1 PCI-E 4.0 x32 Left Riser Slot
1 PCI-E 4.0 x16 Right Riser Slot
M.2 Interface: 2 PCI-E 3.0 x2
M.2 Form Factor: 2280, 22110
M.2 Key: M-Key

· SATA3 (6 Gbps)2 SATA3 (6 Gbps) ports; Asmedia ASM1061
SATA3 (6 Gbps)16 SATA3 (6 Gbps) ports; 16 SATA3 via 2x Slim SAS

· 2 Broadcom BCM57416 10GBase-T,
1 Realtek RTL8211F PHY (dedicated IPMI)

• 8th/9th Generation Intel® Core™ i9/Core™ i7/Core™i5/Core™i3/Pentium®/Celeron® Processor, Intel® Xeon® E-2100 Processor, Intel® Xeon® E-2200 Processor
Single Socket LGA-1151 (Socket H4) supported, CPU TDP support Up to 95W TDP

• Intel® C246

• Up to 128GB Unbuffered ECC/non-ECC UDIMM, DDR4-2666MHz, in 4 DIMM slots

• 1 PCI-E 3.0 x4,
1 PCI-E 3.0 x1,
2 PCI-Ex16 slots are running at NA/16, or 8/8
1 - 5V PCI 32bit
M.2 Interface: 2 PCI-E 3.0 x4
M.2 Form Factor: 2242/2260/2280/22110
M.2 Key: M-Key
M.2#1 are shared with PCI-Ex4 slot, M.2#2 is shared with U.2
U.2 Interface: 1 PCI-E 3.0 x4

• 1 HDMI port, 1 DVI - D port, 1 DP (DisplayPort) port,
Intel UHD P630 graphic(For CPU Xeon E-21XXG\E-22XXG series only)

• Intel® C246 controller for 8 SATA3 (6 Gbps) ports; RAID 0,1,5,10

• Single LAN with Intel® Ethernet Controller I210-AT
Single LAN with Intel® PHY I219LM LAN controller
Support vPro
Single LAN with
Gigabit LAN WiFi + Bluetooth 5.0

· AMD EPYC™ 7001 series (Naples) Processors, AMD EPYC™ 7000 Series
· System on Chip
· 2 TB ECC Registered, DDR4-2666MHz SDRAM in 16 DIMMs
8-channel memory bus

· 1 PCI-E 3.0 x16 for Left riser card support
1 PCI-E 3.0 x16 for Right riser card support
1 PCI-E 3.0 x16 SIOM LAN Networking Slot
1 PCI-E 3.0 x24 Proprietary Slot (for Supermicro storage add-on card)
M.2 Interface: 1 SATA/PCI-E 3.0 x4
M.2 Form Factor: 2280, 22110
M.2 Key: M-Key

· SATA3 (6 Gbps)6 SATA3 (6 Gbps) ports;
· 1 Realtek RTL8211F PHY (dedicated IPMI)

· AMD EPYC™ 7002 series (Rome) Processors, AMD EPYC™ 7002 series and next generation processors
· System on Chip
· 4 TB ECC Registered, DDR4-3200MHz SDRAM in 16 DIMMs
· 1 PCI-E 4.0 x16 for Left riser card support
1 PCI-E 4.0 x16 for Right riser card support
1 PCI-E 4.0 x16 SIOM LAN Networking Slot
1 PCI-E 4.0 x24 Proprietary Slot (for Supermicro storage add-on card)
M.2 Interface: 1 SATA/PCI-E 3.0 x4
M.2 Form Factor: 22110, 2280
M.2 Key: M-Key
· SATA3 (6 Gbps)6 SATA3 (6 Gbps) ports;
· 1 Realtek RTL8211F PHY (dedicated IPMI)

• 8th/9th Generation Intel® Core™ i9/Core™ i7/Core™i5/Core™i3/Pentium®/Celeron® Processor, Intel® Xeon® E-2100 Processor, Intel® Xeon® E-2200 Processor
Single Socket LGA-1151 (Socket H4) supported, CPU TDP support Up to 95W TDP

• Intel® C246

• Up to 128GB Unbuffered ECC/non-ECC UDIMM, DDR4-2666MHz, in 4 DIMM slots

• 1 PCI-E 3.0 x4,
1 PCI-E 3.0 x1,
2 PCI-Ex16 slots are running at NA/16, or 8/8
1 - 5V PCI 32bit
M.2 Interface: 2 PCI-E 3.0 x4
M.2 Form Factor: 2242/2260/2280/22110
M.2 Key: M-Key
M.2#1~2 are shared with PCI-Ex4 slot, M.2#2 is shared with U.2
U.2 Interface: 1 PCI-E 3.0 x4

• 1 HDMI port, 1 DVI - D port, 1 DP (DisplayPort) port, 1 VGA port,
Intel UHD P630 graphic(For Xeon E-21xxG/E-22xxG series only)

• Intel® C246 controller for 8 SATA3 (6 Gbps) ports; RAID 0,1,5,10

• Single LAN with Intel® Ethernet Controller I210-AT
Shared with IPMI
Single LAN with Intel® PHY I219LM LAN controller

· AMD EPYC™ 7002 series (Rome) Processors, AMD EPYC™ 7002 series and next generation processors
· System on Chip
· 2 TB ECC Registered, DDR4-3200MHz SDRAM in 8 DIMMs

· 1 PCI-E 4.0 x16 for Left riser card support
1 PCI-E 4.0 x16 for Right riser card support
1 PCI-E 4.0 x16 SIOM LAN Networking Slot
1 PCI-E 4.0 x24 Proprietary Slot (for Supermicro storage add-on card)
M.2 Interface: 4 SATA/PCI-E 4.0 x4
M.2 Form Factor: 22110, 2280, 2260, 2242
M.2 Key: M-Key

· SATA3 (6 Gbps)6 SATA3 (6 Gbps) ports;
· 1 Realtek RTL8211F PHY (dedicated IPMI)

• 8th/9th Generation Intel® Core™ i9/Core™ i7/Core™i5/Core™i3/Pentium®/Celeron® Processor, Intel® Xeon® E-2100 Processor, Intel® Xeon® E-2200 Processor
Single Socket LGA-1151 (Socket H4) supported, CPU TDP support Up to 95W TDP

• Intel® C246

• Up to 128GB Unbuffered ECC/non-ECC UDIMM, DDR4-2666MHz, in 4 DIMM slots

• 1 PCI-E 3.0 x4,
1 PCI-E 3.0 x1,
2 PCI-Ex16 slots are running at NA/16, or 8/8
1 - 5V PCI 32bit
M.2 Interface: 2 PCI-E 3.0 x4
M.2 Form Factor: 2242/2260/2280/22110
M.2 Key: M-Key
M.2#1 are shared with PCI-Ex4 slot, M.2#2 is shared with U.2
U.2 Interface: 1 PCI-E 3.0 x4

• 1 HDMI port, 1 DVI - D port, 1 DP (DisplayPort) port,
Intel UHD P630 graphic(For CPU Xeon E-21XXG/E-22XXG series only)

• Intel® C246 controller for 8 SATA3 (6 Gbps) ports; RAID 0,1,5,10

• Single LAN with Intel® Ethernet Controller I210-AT
Single LAN with Intel® PHY I219LM LAN controller
Support vPro

· AMD EPYC™ 7002 series (Rome) Processors, AMD EPYC™ 7002 series and next generation processors
System on Chip
· 2 TB ECC Registered, DDR4-3200MHz SDRAM in 8 DIMMs
· 1 PCI-E 4.0 x16 for Right riser card support
1 PCI-E 4.0 x8 Left Hand Riser
M.2 Interface: 4 SATA/PCI-E 4.0 x4
M.2 Form Factor: 22110
1 PCI-E 4.0 x16 for AIOM networking, AIOM

• Intel® Pentium™ Processor N3710., Single Socket FCBGA1170 supported, CPU TDP support 6W

• System-on-Chip

• Up to 8GB 1600MHz DDR3 Non-ECC SO-DIMM in 2 sockets

• 1 PCI-E 2.0 x1 (in x8),
1 Mini-PCIe (mSATA support)

• Quad GbE LAN with Intel® i210-AT

• 1 HDMI, 1 DP, Intel HD Graphics,
VGA port for BMC

• 2 USB 3.0 ports (2 rear), 7 USB 2.0 (2 rear, 4 via header(s), 1 Type A)

• I/O: 1 SATA DOM, 2 COM, TPM 1.2 header, ALC 888S HD Audio

• IPMI 2.0 with dedicated Port and KVM

• Supports 12V DC power input

· AMD EPYC™ 7002 series (Rome) Processors, AMD EPYC™ 7003 series (Milan) Processors
· System on Chip
· 4 TB ECC Registered, DDR4-3200MHz SDRAM in 16 DIMMs
8-channel memory bus

· 1 PCI-E 4.0 x16 for Left riser card support
1 PCI-E 4.0 x16 for Right riser card support
M.2 Interface: 2 PCI-E 4.0 x4
M.2 Form Factor: 2280, 22110
M.2 Key: M-Key
2 PCI-E 4.0 x16 slots (16/NA/NA or 8/8/NA or 8/4/4) for AIOM networking

· SATA3 (6 Gbps)8 SATA3 (6 Gbps) ports; 8 SATA3 via 1x Slim SASx8
SATA3 (6 Gbps)8 SATA3 (6 Gbps) ports; 8 SATA3 via 2x Slim SASx4

· 1 Realtek RTL8211F PHY (dedicated IPMI)
