• Intel® 8th Generation Core™ i5-8365UE Processor

• Dual Channel DDR4 2400MHz SO-DIMM, up to 64GB

• Intel UHD Graphics 620 with 4K and 24 EU for Vision Solution

• 3 display support(DP++, HDMI and 48-bit LVDS)

• Small form factor with rich I/O: 2 GbE, 8 USB and 6 COM

• Rich expansion: 3 x M.2 (B/E/M key) for NVMe/SATA/Wifi/BT/LTE

• 12-24V wide range power input with RVP and TVS

• Without heatsink for customer flexible thermal design

• Intel® 8th Generation Core™ i5-8365UE Processor

• Dual Channel DDR4 2400MHz SO-DIMM, up to 64GB

• Intel UHD Graphics 620 with 4K and 24 EU for Vision Solution

• 3 display support(DP++, HDMI and 48-bit LVDS)

• Small form factor with rich I/O: 2 GbE, 8 USB and 6 COM

• Rich expansion: 3 x M.2 (B/E/M key) for NVMe/SATA/Wifi/BT/LTE

• 12-24V wide range power input with RVP and TVS

• Intel® Celeron® 4305UE Processor

• Dual Channel DDR4 2133MHz SO-DIMM, up to 64GB

• Intel UHD Graphics 620 with 4K and 24 EU for Vision Solution

• 3 display support(DP++, HDMI and 48-bit LVDS)

• Small form factor with rich I/O: 2 GbE, 8 USB and 6 COM

• Rich expansion: 3 x M.2 (B/E/M key) for NVMe/SATA/Wifi/BT/LTE

• 12-24V wide range power input with RVP and TVS

• Without heatsink for customer flexible thermal design

• Intel® Celeron® 4305UE Processor

• Dual Channel DDR4 2133MHz SO-DIMM, up to 64GB

• Intel UHD Graphics 610 with 4K and 24 EU for Vision Solution

• 3 display support(DP++, HDMI and 48-bit LVDS)

• Small form factor with rich I/O: 2 GbE, 8 USB and 6 COM

• Rich expansion: 3 x M.2 (B/E/M key) for NVMe/SATA/Wifi/BT/LTE

• 12-24V wide range power input with RVP and TVS

• Single socket H4 (LGA 1151) supports Intel® Xeon® processor E3-1200 v6/v5, Intel® 7th/6th Gen. Core™i7/i5/ i3 series, Intel® Celeron® and Intel® Pentium®

• Intel® C236 chipset

• Up to 64GB DDR4 2400MHz ECC/Non-ECC Unbuffered UDIMM; 4 DIMM slots

• 1 PCI-E 3.0 x16 (in x16),
2 PCI-E 3.0 x4 (in x8)

• Dual 10GbE LAN via Intel® X550-BT2
Dual GbE LAN via Intel® i219LM + i210AT

• 2 DP, 1 DVI-I, 3 independent displays via Intel HD Graphics, VGA port for BMC

• 4 SATA3 (6Gbps) via C236; RAID 0, 1, 5, 10

• I/O: 1 SATA DOM, 2 COM, TPM 1.2 header, ALC 888S HD Audio

• IPMI, AMT vPro

• Supports 12V DC power input

• Single socket H4 (LGA 1151) supports
Intel® 7th/6th Gen. Core i7/i5/i3 series,
Intel® Celeron® and Intel® Pentium®

• Intel® Q170 Express chipset

• Up to 64GB DDR4 2400MHz Non-ECC Unbuffered UDIMM; 4 DIMM slots

• 1 PCI-E 3.0 x16
2 PCI-E 3.0 x4 (in x8 slot)

• Dual GbE LAN w/ Intel i219LM + i210AT

• 2 DP, 1 DVI-I, 3 independent displays via Intel HD Graphics, VGA port for BMC

• 4 SATA3 (6Gbps) via Q170; RAID 0, 1, 5, 10

• I/O: 1 SATA DOM, 2 COM, TPM 1.2 header, ALC 888S HD Audio

• IPMI, AMT vPro

• Supports 12V DC power input

• Single socket H4 (LGA 1151) supports Intel® Xeon® processor E3-1200 v6/v5, Intel® 7th/6th Gen. Core™i7/i5/ i3 series, Intel® Celeron® and Intel® Pentium®

• Intel® C236 chipset

• Up to 64GB DDR4 2400MHz ECC/Non-ECC Unbuffered UDIMM; 4 DIMM slots

• 1 PCI-E 3.0 x16 (in x16),
2 PCI-E 3.0 x4 (in x8)

• Dual GbE LAN w/ Intel i219LM + i210AT

• 2 DP, 1 DVI-I, 3 independent displays via Intel HD Graphics, VGA port for BMC

• 4 SATA3 (6Gbps) via C236; RAID 0, 1, 5, 10

• I/O: 1 SATA DOM, 2 COM, TPM 1.2 header, ALC 888S HD Audio

• IPMI, AMT vPro

• Supports 12V DC power input

• Single socket H4 (LGA 1151) supports
Intel® 7th/6th Gen. Core i7/i5/i3 series,
Intel® Celeron® and Intel® Pentium®

• Intel® Q170 Express chipset

• Up to 32GB Unbuffered Non-ECC SO-DIMM DDR4 2400MHz; 2 DIMM slots

• 1 PCI-E 3.0 x16, Mini-PCI-E (mSATA support)
M.2 PCI-E 3.0 x4 (SATA support), M Key 2242/80

• Dual GbE LAN w/ Intel i219LM + i210AT

• 1 HDMI, 1 DP, 1 DVI-I, Intel HD Graphics
3 independent displays

• 5 SATA3 (6Gbps) via Q170; RAID 0, 1, 5, 10

• 2 SATA DOM, 2 COM ports, TPM header, ALC 888S HD Audio

• AMT, vPro

• Supports 12V DC power input

• Intel Xeon processor E3-1585 v5,
Single socket FCBGA 1440,
4-Core, 8 Threads, 65W

• Intel® C236 chipset

• Up to 32GB ECC Unbuffered SO-DIMM DDR4 2133MHz; 2 DIMM slots

• 1 PCI-E 3.0 x16, 1 Mini-PCIe (mSATA support), 1 M.2 PCIe 3.0 x4 (SATA support), M Key 2242/80

• 4x 1GbE LAN w/ Intel I219LM, I210AT, I350AM2

• 1 DVI-A, Graphics from AST2400

• 4 SATA3 (6Gbps) via C236;
RAID 0, 1, 5, 10

• 2 SATA DOM, 1 COM (in RJ45),TPM header, ALC 888S HD Audio

• Integrated IPMI 2.0 and KVM with
Shared LAN (Intel I210AT)

• Supports Intel VHD and 12V DC power input

• Intel® Xeon® processor E3-1515M v5, Single socket FCBGA 1440, 4-Core, 8 Threads, 45W

• Intel® CM236 Chipset

• Up to 32GB ECC/Non-ECC Unbuffered SO-DIMM DDR4 2133MHz; 2 DIMM slots

• 1 PCI-E 3.0 x16, 1 Mini-PCI-E (mSATA support), 1 M.2 PCI-E 3.0 x4 (SATA support), M Key 2242/80

• 4x 1GbE LAN w/ Intel I219LM, I210AT, I350AM2

• 1 HDMI2.0, 1 DP1.2, 1 DVI-I, Intel Iris Pro Graphics P580, 3 independent displays

• 4 SATA3 (6Gbps) via CM236, RAID 0, 1, 5, 10

• 2 SATA DOM, 1 COM (in RJ45), TPM header, ALC 888S HD

• Audio AMT, vPro

• Supports 12V DC power input

• Single socket H4 (LGA 1151) supports Intel® 7th/6th Gen. Core i7/i5/i3 series, Intel® Celeron® and Intel® Pentium®

• Intel® Q170 Express chipset

• Up to 32GB Unbuffered Non-ECC SO-DIMM DDR4 2400MHz; 2 DIMM slots

• 1 PCI-E 3.0 x16, Mini-PCI-E (mSATA support)
M.2 PCI-E 3.0 x4 (SATA support), M Key 2242/80

• Dual GbE LAN w/ Intel i219LM + i210AT

• 1 HDMI, 1 DP, 1 LVDS, Intel HD Graphics 3 independent displays

• 5 SATA3 (6Gbps) via Q170; RAID 0, 1, 5, 10

• 2 SATA DOM, 1 COM,TPM header, ALC 888S HD Audio

• AMT, vPro

• Supports 12V DC power input

• Single socket H4 (LGA 1151) supports Intel® 7th/6th Gen. Core i7/i5/i3 series, Intel® Celeron® and Intel® Pentium®

• Intel® H110 Chipset

• Up to 32GB Unbuffered Non-ECC UDIMM DDR4 2400MHz; 2 DIMM slots

• Expansion slots:
1 PCI-E 3.0 x16
1 PCI-E 2.0 x4 w/ open slots
1 PCI-E 2.0 x1

• Intel® i219LM GbE LAN

• 4 SATA3 (6Gbps) via H110, Intel® RST

• HDMI, DP, DVI-D
Intel HD Graphics
2 Independent Displays

• 1 SATA DOM, 2 COM ports, TPM header, ALC 888S HD Audio 7.1

• 4 USB 3.0 (2 rear + 2 via header(s))
6 USB 2.0 (2 rear + 4 via header(s))
