• 2U chassis support for SMC Proprietary WIO motherboards max. motherboard size - 12" x 13", 13" x 13.68". Support up to 12"x13" MB with rear 2.5" HDD option installed.

• 24 x 2.5" hot-swap drive bay

• 24-port 2U SAS 6Gbps direct-attached backplane, support up to 24x 2.5-inch SAS2/SATA3 HDD/SSD

• 1U 920W Redundant Platinum Super Quiet power supply W/PMbus

• 4 full-height & half-length expansion slot(s) , 3 low-profile expansion slot(s)

• 3x 8cm high-performance PWM fan(s)

• Optional 5 x 6cm fan cooling module for 826B/216B

• 2U chassis support for max. motherboard size - 13" x 13.68", E-ATX and ATX. Support up to 12"x13" MB with rear 2.5" HDD option installed.

• 24 x 2.5" hot-swap SAS/SATA drive bay

• 24-port 2U SAS 6Gbps direct-attached backplane, support up to 24x 2.5-inch SAS2/SATA3 HDD/SSD

• 1U 920W Redundant Platinum Super Quiet power supply W/PMbus

• 7 low-profile expansion slot(s)

• 3x 8cm (7000 RPM) hot-swap PWM cooling fan(s)

• Optional 5 x 6cm fan cooling module for 826B/216B

• 2U rackmount chassis - supports for maximum motherboard sizes: 15.2" x 13.2"

• 16 x 2.5" hot-swap SAS3/SATA drive bay

• 16-port 2U SAS3 12Gbps direct-attached backplane, support up to 16x 2.5-inch SAS3/SATA3 HDD/SSD

• 1U 800/1000W Redundant Power Supply 38mm Width

• 11 low-profile expansion slot(s)

• 4 x 8cm high-performance PWM fan(s)

• 2U chassis supports for maximum motherboard sizes - 13.68" x 13", E-ATX 12" x 13", ATX 12" x 10" motherboards

• 8 x 2.5" hot-swap SAS/SATA drive bay, 1 x 5.25" drive bay

• 8-port 2U TQ backplane (W/O AMI9071/72 enclosure management), support up to 8x 2.5-inch SAS/SATA HDD/SSD

• 1U 600W platinum efficiency multiple output power supply w/pmbus

• 7 low-profile expansion slot(s)

• 3x 8cm high-performance PWM fan(s)

• 2U chassis supports for maximum motherboard sizes - 13.68" x 13", E-ATX 12" x 13", ATX 12" x 10" motherboards

• 16 x 2.5" hot-swap SAS3/SATA drive bay, 1 x 5.25" drive bay, optional 2 x 2.5" hot-swap SAS3/SATA drive bay

• 1U 1200W/1000W Titanium Power Supply W/PMbus W76xL336xH40mm

• 7x Low profile I/O Expansion Slot

• 3x 8cm high-performance PWM fan(s)

• 2U chassis supports for maximum motherboard sizes - SMC Proprietary WIO , 13.68" x 13" motherboards

• 16 x 2.5" hot-swap SAS3/SATA drive bay, 1 x 5.25" drive bay

• 1U 1200W/1000W Titanium Power Supply W/PMbus W76xL336xH40mm

• 4 full-height & full-length expansion slot(s) , 3 low-profile expansion slot(s)

• 3x 8cm high-performance PWM fan(s)

• 2U chassis supports for maximum motherboard sizes - 13.68" x 13", E-ATX 12" x 13", ATX 12" x 10" motherboards

• 16 x 2.5" hot-swap SAS3/SATA drive bay, 1 x 5.25" drive bay

• 16-port 2U SAS3 12Gbps direct-attached backplane, support up to 16x 2.5-inch SAS3/SATA3 HDD/SSD

• 1U 920W Redundant Platinum Level Power Supply

• 7 low-profile expansion slot(s)

• 3x 8cm high-performance PWM fan(s)

• 2U chassis supports for maximum motherboard sizes - 13.68" x 13", E-ATX 12" x 13", ATX 12" x 10" motherboards

• 16 x 2.5" hot-swap SAS3/SATA drive bay, 1 x 5.25" drive bay

• 16-port 2U SAS3 12Gbps direct-attached backplane, support up to 16x 2.5-inch SAS3/SATA3 HDD/SSD

• 1U 1200W/1000W Titanium Power Supply W/PMbus W76xL336xH40mm

• 7 low-profile expansion slot(s)

• 3x 80mm heavy duty fan(s) with PWM fan(s) speed control

• 2U chassis supports for maximum motherboard sizes - SMC Proprietary WIO , 13.68" x 13" motherboards

• 16 x 2.5" hot-swap SAS/SATA drive bay w/ full SES-II support on SAS motherboards, 1 x 5.25" drive bay

• 16-port 2U SAS 6Gbps direct-attached backplane, support up to 16x 2.5-inch SAS2/SATA3 HDD/SSD

• 1U 740W Redundant Platinum Power Supply W/PMbus

• 4 full-height & full-length expansion slot(s) , 3 low-profile expansion slot(s)

• 3x 8cm high-performance PWM fan(s)
