· AMD EPYC™ 7002 series (Rome) Processors, AMD EPYC™ 7002 series and next generation processors
· System on Chip
· 8 TB ECC Registered, DDR4-3200MHz SDRAM in 32 DIMMs
· 19 PCI-E 4.0 x8 SlimSAS
· 1 PCI-E 4.0 x4 SlimSAS

· AMD EPYC™ 7002 series (Rome) Processors, AMD EPYC™ 7002 series and next generation processors
· System on Chip
· 8 TB ECC Registered, DDR4-3200MHz SDRAM in 32 DIMMs
· 4 PCI-E 4.0 x8 SlimSAS
1 PCI-E 4.0 x4 SlimSAS
M.2 Interface: 2 PCI-E 4.0 x4
M.2 Form Factor: 22110
M.2 Key: M-Key

· AMD EPYC™ 7001 series (Naples) Processors, AMD EPYC™ 7000 Series
· System on Chip
· 2 TB ECC Registered, DDR4-2666MHz SDRAM in 16 DIMMs
8-channel memory bus

· 1 PCI-E 3.0 x32 Left Riser Slot
1 PCI-E 3.0 x16 Right Riser Slot
M.2 Interface: 2 PCI-E 3.0 x2
M.2 Form Factor: 2280, 22110
M.2 Key: M-Key
M.2-C1 can support PCI-E x4, when only install 1pcs M.2

· SATA3 (6 Gbps)16 SATA3 (6 Gbps) ports; Hybrid use from Four (4) internal NVMe ports by BIOS option.
SATA3 (6 Gbps)2 SATA3 (6 Gbps) ports; Asmedia ASM1061

· 2 Broadcom BCM57416 10GBase-T,
1 Realtek RTL8211F PHY (dedicated IPMI)

· AMD EPYC™ 7002 series (Rome) Processors, AMD EPYC™ 7002 series and next generation processors
· System on Chip
· 2 TB ECC Registered, DDR4-3200MHz SDRAM in 8 DIMMs
· 1 PCI-E 4.0 x32 Left Riser Slot
1 PCI-E 4.0 x16 Right Riser Slot
M.2 Interface: 2 SATA/PCI-E 3.0 x2
M.2 Form Factor: 2280, 22110
M.2 Key: M-Key
M.2-C1 can support PCI-E x4, when only install 1pcs M.2

· SATA3 (6 Gbps)16 SATA3 (6 Gbps) ports; Hybrid use from Four(4) internal NVMe ports by BIOS option.
SATA3 (6 Gbps)2 SATA3 (6 Gbps) ports; Asmedia ASM1061
2 Broadcom BCM57416 10GBase-T,
1 Realtek RTL8211F PHY (dedicated IPMI)

· AMD EPYC™ 7002 series (Rome) Processors, AMD EPYC™ 7002 series and next generation processors
· System on Chip
· 4 TB ECC Registered, DDR4-3200MHz SDRAM in 16 DIMMs
8-channel memory bus

· 1 PCI-E 4.0 x32 Left Riser Slot
1 PCI-E 4.0 x16 Right Riser Slot
M.2 Interface: 2 PCI-E 3.0 x2
M.2 Form Factor: 2280, 22110
M.2 Key: M-Key

· SATA3 (6 Gbps)2 SATA3 (6 Gbps) ports; Asmedia ASM1061
SATA3 (6 Gbps)16 SATA3 (6 Gbps) ports; 16 SATA3 via 2x Slim SAS

· 2 Broadcom BCM57416 10GBase-T,
1 Realtek RTL8211F PHY (dedicated IPMI)

· AMD EPYC™ 7001 series (Naples) Processors, AMD EPYC™ 7000 Series
· System on Chip
· 2 TB ECC Registered, DDR4-2666MHz SDRAM in 16 DIMMs
8-channel memory bus

· 1 PCI-E 3.0 x16 for Left riser card support
1 PCI-E 3.0 x16 for Right riser card support
1 PCI-E 3.0 x16 SIOM LAN Networking Slot
1 PCI-E 3.0 x24 Proprietary Slot (for Supermicro storage add-on card)
M.2 Interface: 1 SATA/PCI-E 3.0 x4
M.2 Form Factor: 2280, 22110
M.2 Key: M-Key

· SATA3 (6 Gbps)6 SATA3 (6 Gbps) ports;
· 1 Realtek RTL8211F PHY (dedicated IPMI)

· AMD EPYC™ 7002 series (Rome) Processors, AMD EPYC™ 7002 series and next generation processors
· System on Chip
· 4 TB ECC Registered, DDR4-3200MHz SDRAM in 16 DIMMs
· 1 PCI-E 4.0 x16 for Left riser card support
1 PCI-E 4.0 x16 for Right riser card support
1 PCI-E 4.0 x16 SIOM LAN Networking Slot
1 PCI-E 4.0 x24 Proprietary Slot (for Supermicro storage add-on card)
M.2 Interface: 1 SATA/PCI-E 3.0 x4
M.2 Form Factor: 22110, 2280
M.2 Key: M-Key
· SATA3 (6 Gbps)6 SATA3 (6 Gbps) ports;
· 1 Realtek RTL8211F PHY (dedicated IPMI)

· AMD EPYC™ 7002 series (Rome) Processors, AMD EPYC™ 7002 series and next generation processors
· System on Chip
· 2 TB ECC Registered, DDR4-3200MHz SDRAM in 8 DIMMs

· 1 PCI-E 4.0 x16 for Left riser card support
1 PCI-E 4.0 x16 for Right riser card support
1 PCI-E 4.0 x16 SIOM LAN Networking Slot
1 PCI-E 4.0 x24 Proprietary Slot (for Supermicro storage add-on card)
M.2 Interface: 4 SATA/PCI-E 4.0 x4
M.2 Form Factor: 22110, 2280, 2260, 2242
M.2 Key: M-Key

· SATA3 (6 Gbps)6 SATA3 (6 Gbps) ports;
· 1 Realtek RTL8211F PHY (dedicated IPMI)

· AMD EPYC™ 7002 series (Rome) Processors, AMD EPYC™ 7002 series and next generation processors
System on Chip
· 2 TB ECC Registered, DDR4-3200MHz SDRAM in 8 DIMMs
· 1 PCI-E 4.0 x16 for Right riser card support
1 PCI-E 4.0 x8 Left Hand Riser
M.2 Interface: 4 SATA/PCI-E 4.0 x4
M.2 Form Factor: 22110
1 PCI-E 4.0 x16 for AIOM networking, AIOM

· AMD EPYC™ 7002 series (Rome) Processors, AMD EPYC™ 7003 series (Milan) Processors
· System on Chip
· 4 TB ECC Registered, DDR4-3200MHz SDRAM in 16 DIMMs
8-channel memory bus

· 1 PCI-E 4.0 x16 for Left riser card support
1 PCI-E 4.0 x16 for Right riser card support
M.2 Interface: 2 PCI-E 4.0 x4
M.2 Form Factor: 2280, 22110
M.2 Key: M-Key
2 PCI-E 4.0 x16 slots (16/NA/NA or 8/8/NA or 8/4/4) for AIOM networking

· SATA3 (6 Gbps)8 SATA3 (6 Gbps) ports; 8 SATA3 via 1x Slim SASx8
SATA3 (6 Gbps)8 SATA3 (6 Gbps) ports; 8 SATA3 via 2x Slim SASx4

· 1 Realtek RTL8211F PHY (dedicated IPMI)

· AMD EPYC™ 7002 series (Rome) Processors, AMD EPYC™ 7002 series and next generation processors
· System on Chip
· 4 TB ECC Registered, DDR4-3200MHz SDRAM in 16 DIMMs

· 1 PCI-E 4.0 x16 for Right riser card support
1 PCI-E 4.0 x16 for Left riser card support
M.2 Interface: 2 SATA/PCI-E 4.0 x4
M.2 Form Factor: 22110
1 PCI-E 4.0 x16 PCI-E 4.0 AOM Slot for AIOM networking

· Intel® Xeon® E-2100 Processor, Intel® Xeon® E-2200 Processor
Single Socket LGA-1151 (Socket H4) supported, CPU TDP support Up to 95W TDP
· Intel® C246
· Up to 128GB Unbuffered ECC UDIMM, DDR4-2666MHz, in 4 DIMM slots
· 1 PCI-E 3.0 x16 slots (16/NA or 8/8)
1 M.2 M-Key SATA/PCI-E 3.0 x4, 2280/22110
· Dual LAN with
Two(2)10GbE Ethernet ports from KR interface to BP
